Dewatering Equipment
Hauler Hydraulic Sand And Slurry Pump
Advanced Hydraulic Solutions
The DAE Pumps Hauler Hydraulic Sand & Slurry Pump, now available through UAE Pump and Dredge, delivers high-performance dredging and slurry transport for the most demanding environments. With a capacity of up to 2,000 cubic meters of solids per hour, this hydraulic-driven pump is engineered for efficient handling of abrasive slurries, high solid loads, and large-scale dredging.
Its advanced non-clogging suction design handles solids up to 3.9 inches in diameter and transfers material through a 16-inch discharge line with solid concentrations of up to 30%. As a flagship product in DAE Pumps’ hydraulic lineup, the Hauler stands out for its operational reliability, adaptability, and durability in high-wear applications.
Versatile and Powerful for Extreme Conditions
Designed with versatility in mind, the Hauler Hydraulic Sand & Slurry Pump supports multiple deployment configurations—whether cable-suspended or excavator-mounted—to meet varied project demands. Its modularity makes it ideal for both deepwater dredging and shallow sediment agitation.
Optional attachments like an agitator head or water jetting ring can be added to dislodge sediment or organic debris efficiently, such as aquatic vegetation, boosting overall pumping efficiency and minimizing downtime.
Key Features of the Hauler Hydraulic Sand & Slurry Pump
- Exceptional Durability: Engineered for abrasion resistance and extended operating life in the harshest dredging conditions
- Customizable Sizes: Available in sizes ranging from 3 to 16 inches to suit a wide range of applications
- High-Volume Handling: Capable of pumping up to 2,000 m³/h of solids
- Solids Throughput: Efficiently moves slurry with up to 30% solid content
- Operational Depth: Functional in operations reaching depths of 250 meters
- Hydraulic Motor Power: Delivers strong torque and consistent performance via a robust hydraulic motor system
Technical Specifications
Hydraulic Performance
- Max Flow Capacity: 2,860 GPM (650 m³/h)
- Max Head: 89.5 ft (27 m)
- Discharge Outlet: 12" (300 mm)
- Impeller: 16" (405 mm), 3-blade closed design
- Max Solid Handling: 3.6" (90 mm)
Construction Materials
- Pump Casing: Spheroidal Cast Iron (EN-GJS500-7)
- Motor Housing: Cast Iron (EN-GJL-250)
- Wear Parts: High Chrome (EN-GJN-HV600 / XCr18)
- Main Shaft: High-Tensile Steel 39NiCrMo3 (AISI 9840)
Hydraulic Motor
- Displacement: 9.8 cu. in (160 cc)
- Max Oil Flow: 72 GPM (270 l/min)
- Max Pressure: 4,351 PSI (300 bar)
- Power Rating: 185 HP (475 kW)
- Speed: 1,450 RPM
Seal System & Lubrication
- Motor Side Seals: 2 BUNA Lip Seals
- Impeller Side Seals: 5 Lip Seals (3 BUNA + 2 PTFE) + 1 V-ring (TPU)
- Lubrication: ISO 320 oil for reliable sealing performance
Complete Hydraulic Dewatering Solutions
At UAE Pump and Dredge, we deliver more than just equipment—we offer integrated dewatering solutions tailored to your site needs. Whether you’re working on port deepening, tailings pond recovery, or remote pit drainage, the Hauler series and our broader hydraulic pump range provide dependable results with minimal maintenance.
With modular design, sealed motor systems, and operator-friendly features, our equipment reduces downtime. It simplifies servicing, making us a trusted partner in dredging and dewatering operations across the UAE and the Middle East.
